Screw Bolt Pro ETA C2 12 x 110 carton 200

A high strength structural anchoring solution for internal and external bolting and fixing of construction and engineering components where approved concrete screw anchors and maximum performance is required. Fully independently tested to the highest European standards and are awarded the prestigious ETA certification (European Technical Approval) and therefore comply with Australian NCC standards, full technical load data sheets are available. ETA Option 1: Approved for cracked and non-cracked concrete. Fully compliant to AS 5216:2018 / SA TS 101:2015 standards.

Features:

• Quantity: 200
• ETA Option 1
• Seismic Rating: C1 + C2 Seismic
• Specifications: ETA / Fire Rated / AS 5216
• Shank Diameter: 12mm
• Drill Size: 12mm
• Length: 110mm
• Effective Anchor Depth: Please contact us for full information
• Wrench Size:17mm
• Head Diameter: 25mm
• Finish: Ceramic Coated 1000Hr Spray Tested
• Recommend Tension Load (32MPa): Please request the ETA certification

Whilst great care is taken in compiling technical data on Scrooz Fasteners products, all information, recommendations, or suggestions regarding the use of such products are made without guarantee, since the conditions of use are beyond our control. It is the customer?s responsibility to ensure that each product is fit for the purpose for which they intend for it to be used and that the conditions of use are suitable. All load data is presented inclusive of safety factors. Technical data sheets with further detail are available for all our products upon request, at any time.
